Cryptographic libraries for ARM CPU

Cryptovia ARM library supports the following security features for products based on the ARM architecture:



AES Algorithms for ARM CPU

FIPS 197 compliant



Two different AES implementations in ARM assembly language are available:

  1. One has been designed for speed for products requiring high throughput.
  2. Another one has been optimized with small code footprint objective for products where any byte memory counts.



The table below shows the memory occupation and the timings of the two implementations for each AES key length on a ARM Cortex-M3 core.



Algorithm Version ROM RAM Cycles per 16-byte
encryption/decryption		 Throughput Mbit/s @50 MHz
encryption/decryption
AES-128 Speed 4 298 72 1 463 / 2 773 4,17 / 2,20
Code 1 424 72 4 708 / 6 258 1,30 / 0,98
AES-192 Speed 4 656 104 1 712 / 3 257 3,56 / 1,87
Code 1 628 104 5 566 / 7 230 1,10 / 0,84
AES-256 Speed 4 464 88 2 245 / 4 494 2,72 / 1,36
Code 1 644 88 6 550 / 8 624 0,93 / 0,71



Contact us for an evaluation version of the AES library.

DES Algorithms for ARM CPU

FIPS 46 compliant



One DES/TDES implementation in ARM assembly language is available.



The table below shows the memory occupation and the timings of the implementation on a ARM Cortex-M3 core.



Algorithm ROM RAM Cycles per 8-byte block
encryption / decryption		 Throughput Kbit/s @50 MHz
encryption / decryption
DES 1 452 80 26 854 / 26 857 116 / 116
TDES-2K 1 452 112 80 588 / 80 596 38,7 / 38,7
TDES-3K 1 452 112 80 592 / 80 600 38,7 / 38,7



Contact us for an evaluation version of the DES library.

Hash Functions for ARM CPU

FIPS 180, FIPS 198 and RFC 1321 compliant



One implementation in ARM assembly language of the hash functions MD5, SHA-1, SHA-256/224 and SHA-512/384 is available.
HMAC constructions based on those hash functions are also available.



The table below shows the memory occupation and the timings of the implementations on a ARM Cortex-M3 core.



Algorithm ROM RAM Cycles to process
50 bytes		 Throughput
Mbit/s @50 MHz
MD5 844 144 2 813 6,78
HMAC-MD5 1 062 248 12 845 1,48
SHA-1 728 148 5 785 3,98
HMAC-SHA-1 946 248 20 699 0,92
SHA-256 / SHA-224 1 040 188 5 835 3,27
HMAC-SHA-256/224 1 476 272 24 879 0,76
SHA-512 / SHA-384 2 012 304 18 226 1,04
HMAC-SHA-512/384 2 448 496 76 439 0,25



Contact us for an evaluation version of the hash library.

Deterministic Random Bits Generators for ARM CPU

NIST SP 800-90A compliant



Implementations for pseudo random numbers generation are available. The generations are based on AES encryptions, or hash functions or HMAC computations as described in the NIST SP 800-90A standard.



The table below shows the memory occupation and the timings of the implementations on a ARM Cortex-M3 core.



Algorithm ROM RAM Cycles to generate
128 bytes		 Throughput
Kbit/s @50 MHz
DRBG AES-128 2 152 184 61 365 811
DRBG AES-192 2 412 240 83 483 599
DRBG AES-256 2 442 232 97 705 512
DRBG SHA-1 1 920 260 91 513 546
DRBG SHA-256 2 148 328 75 990 658
DRBG SHA-512 3 120 504 192 766 259
DRBG HMAC SHA-1 1 608 488 273 427 182
DRBG HMAC SHA-256 2 140 528 266 859 187
DRBG HMAC SHA-512 3 112 944 659 619 76



Contact us for an evaluation version of the DRBG library.

RSA Algorithms for ARM CPU

PKCS #1 compliant





One RSA implementation, with the core routines written in ARM assembly language, is available. The RSA computation using the CRT method is also supported.
In addition to plain RSA computations, the PSS signature scheme and the OAEP encryption padding method described in the PKCS #1 standard are also available.



The table below shows the memory occupation and the timings of the implementations on a ARM Cortex-M3 core.
The figures for RSA-OAEP and RSA-PSS are obtained with SHA-1 as the hash function for the mask generation function.



Algorithm Key Length ROM RAM Cycles Timing @50 MHz
RSA (e=2^16+1) 1 024 2 404 900 1 070 000 21 ms
2 048 2 404 1 384 4 300 000 86 ms
CRT RSA 1 024 3 216 1 348 16 150 000 323 ms
2 048 3 216 1 412 118 000 000 2,36 s
RSA-OAEP (e=2^16+1) 1 024 5 274 1 492 1 125 000 22 ms
2 048 5 274 2 260 4 400 000 88 ms
RSA-OAEP CRT 1 024 6 046 1 996 16 400 000 328 ms
2 048 6 046 2 944 118 000 000 2,36 s
RSA-PSS (e=2^16+1) 1 024 5 942 1 628 1 100 000 22 ms
2 048 5 942 2 524 4 400 000 88 ms
RSA-PSS CRT 1 024 6 754 1 940 16 500 000 329 ms
2 048 6 754 2 964 119 000 000 2,37 s



Contact us for an evaluation version of the RSA library.

ECDSA for ARM CPU

FIPS 186 compliant



Two different implementations of ECDSA over prime fields in ARM assembly language are available:



  1. One does not take advantage of specific characteristics of the elliptic curves, and hence can support any prime field elliptic curve of any size (including the 5 elliptic curves over prime fields defined in the FIPS 186 standard).
  2. The other one is a dedicated ECDSA implementation for each of the 5 elliptic curves over prime fields defined in the FIPS 186 standard.

For each version, both ECDSA signature generation and ECDSA signature verification are supported.



The table below shows the memory occupation and the timings of the generic ECDSA implementation on a ARM Cortex-M3 core.



Algorithm ROM RAM Cycles for signature
generation / verification		 Timing @50 MHz
generation / verification
ECDSA-192 6 990 1 164 8 200 000 / 17 200 000 163 ms / 343 ms
ECDSA-224 6 990 1 244 11 800 000 / 24 900 000 236 ms / 498 ms
ECDSA-256 6 990 1 332 16 500 000 / 34 700 000 329 ms / 693 ms
ECDSA-384 6 990 1 668 49 100 000 / 101 100 000 0,98 s / 2,02 s
ECDSA-521 6 990 2 084 124 000 000 / 255 000 000 2,49 s / 5,11 s



The table below shows the memory occupation and the timings of the specific ECDSA implementations for the FIPS 186 elliptic curves on a ARM Cortex-M3 core.



Algorithm ROM RAM Cycles for signature
generation / verification		 Timing @50 MHz
generation / verification
ECDSA P-192 7 094 1 108 5 700 000 / 12 200 000 114 ms / 245 ms
ECDSA P-224 7 202 1 188 10 700 000 / 22 600 000 214 ms / 452 ms
ECDSA P-256 7 338 1 268 22 600 000 / 47 000 000 453 ms / 940 ms
ECDSA P-384 7 570 1 588 47 700 000 / 98 300 000 0,95 s / 1,96 s
ECDSA P-521 7 628 1 988 73 700 000 / 153 000 000 1,47 s / 3,05 s



Contact us for an evaluation version of the ECDSA library.
